| Overall LengthThe maximum length of a vessel's hull measured parallel to the waterline.: 8.85 ' (270cm) |
8.85 ' (270cm) |
|
|
| Overall Width (beam)The width at the widest point of inflatable boat: 5' (152cm) or 59 in |
5' (152cm) or 59 in |
|
|
| Inside length : |
64 in (164 cm) |
|
|
| Inside width : |
26 inches (66.04 cm) |
|
|
| Number of chambers : |
3+1+1 (Bow, Starboard, Portside) + Keel+air f |
|
|
| Tube diameterDiameter of the main pontoon / tube: 16 in (40cm) |
16 in (40cm) |
|
|
| Max load capacity : |
520 lbs (236 kg) |
|
|
| Max person capacityThe recommended maximum number of persons marked on a capacity label for an inflatable boat: 3 people |
3 people |
|
|
| Max engine powerThe recommended maximum power for outboard powered inflatable boat: 7 HP (5 KW) |
7 HP (5 KW) |
|
|
| Max engine weightMax engine and related equipment total weight: 115 lbs (52.3 kg) |
115 lbs (52.3 kg) |
|
|
| Max Gross loadingRecommended maximum gross load: 636 lbs (288 kg) |
636 lbs (288 kg) |
|
|
| Recommended motor shaft : |
15 inches -short shaft |
|
|
| Hull materialTube fabric: 0.9 mm PVC coated -1100 Dtex polyester fabric |
0.9 mm PVC coated -1100 Dtex polyester fabric |
|
|
| Hull unit weightWeight of the hull of vessel NOT including floor, railings, console, seats, and any other structures.: 57 lbs (26 kg) |
57 lbs (26 kg) |
|
|
| Boat overall weightWeight of the vessel including deck, railings, console, seats, and any other permanent structures and fittings: 88 lbs (40 Kg) |
88 lbs (40 Kg) |
|
|
| Shipping size : |
44 " x 23 "x 12 " |
|
|
| Shipping weight : |
95 lbs |
|
|
